New 2023 ATC Trailers PLA 3619

Toy Hauler Fifth Wheel

Stock #27608

Fairfield, CA

1 of 6

Specifications

Sleeps	4	Length	37 ft 3 in
Ext Width	8 ft 6 in	Ext Height	13 ft 5 in
Hitch Weight	2750 lbs	GVWR	16800 lbs
Dry Weight	10000 lbs	Cargo Capacity	6800 lbs
Fresh Water Capacity	200 gals	Grey Water Capacity	90 gals
Black Water Capacity	45 gals	Tire Size	235/80R16G
Furnace BTU	35000 btu	Available Beds	Queen
Refrigerator Type	12V	Refrigerator Size	15 cu ft
Convection Cooking	Yes	Cooktop Burners	3
Number of Awnings	1	Axle Weight	7000 lbs
Garage Size	19 ft 5 in	LP Tank Capacity	60 lbs.
Water Heater Capacity	10 gal	Water Heater Type	DSI LP Gas/Electric
TV Info	LR High Def 120V Smart TV	Awning Info	25' Power with Light Strip
Axle Count	2	Shower Type	Standard
Electrical Service	50 amp	VIN	5JX3U3622PE231125

Description

ATC Trailers PLA toy hauler 3619 highlights:

Front Private Bedroom
Full Bathroom
Fuel Filling Station
Exterior Storage

Load up your favorite off-road toys into this fifth wheel toy hauler! It has 19' 5" of cargo space and a cableless rear ramp door with non-slip tread for you to safely load up your toys. The cargo area also has a Happijac bed that can be used for more sleeping space in addition to the queen bed with storage in the front private bedroom. The bedroom has an optional slide to add more interior space too. After a fun day on the trails, freshen up in the full bathroom with the one piece fiberglass shower with an Extend-A-Shower curtain. You can keep your bellies full with the three burner cooktop, convection microwave, and the 12V refrigerator. There are many dining options you can choose to create the perfect spot to enjoy your meals!

With any PLA toy hauler travel trailer or fifth wheel by ATC Trailers you will find a full perimeter welded aluminum frame with six sides welded together for maximum strength and durability. The torsion axles with EZ lube and self-adjusting brakes will make towing easier than ever, and there is a low angle ramp for hassle-free unloading of your toys. Step inside to find dimmable ceiling lights throughout, residential solid surface countertops throughout, all-aluminum cabinets and drawers, and fiberglass batten insulation to keep you comfortable year around. The 500 Series and 700 Series are optional packages that can added to all models. Within the 500 Series you'll find a silver aluminum exterior, insulated walls, and 5,000 lb. tie-down rings to name a few features. The 700 Series includes an aluminum exterior with five color options, upgraded E.P.S. wall insulation (R-7), an Airline Track tie-down system recessed in the floor, and so much more. Don't wait another minute; make a PLA toy hauler yours today!

Features

Standard Features

NOTE: Features and options separated by type below:

---------------------------------------------------

TRAVEL TRAILERS

Exterior

Electric Tongue Jack
Power Awning w/ Light Strip
Entry Door w/ Tinted Window & Friction Hinge
Large Stainless Steel Fold-out Grab Handle
Fold-out Adjustable Step
Cableless Rear Ramp Door w/ Non-Slip Tread
Large Exterior Pass Through Storage w/ 3 Access Doors
Fuel Filling Station
Tongue Storage Cover
Loading Lights at Ramp Door
RVIA Seal
Spare Tire on Gray Steel Wheel
Hide-A-Spare - EZ Access

Interior

7' 6" Interior Height
Fiberglass Batten Insulation in Attic (R-11)
Blackout Roller Shades
(1) Dinette w/Benches (Sleeper)
(1) Sofa (Sleeper) (N/A 2513 & 2816)
All-Aluminum Cabinets & Drawers Throughout (No Wood)

Electrical

Energy Package 1000 (200 Watt Solar Panel, 100 Watt inverter, 30 amp mppt charge controller)
Generator Prep
(2) Battery Prep
High Definition 120v Smart TV
TV Prep in Bedroom (2513, 2816, 2917)
TV Prep Exterior
HD Digital TV Antenna w/WiFi Prep
Stereo AM/FM/Bluetooth w/Interior & Exterior Speakers
Touchscreen User Control Panel
Back-up Camera Prep
120v USB Power Outlets Throughout

Plumbing

DSI LP Gas/Electric Water Heater
Ducted LP Furnace
12v Water Pump w/ Winterizing Tap
City Water Hook-up w/ Fill
20’ Sewer Hose w/ Storage Tube
Waste (Black) Tank Flush
3-Season Package
Exterior Water Spigot

Kitchen

Convection Microwave
Farmhouse Single Bowl Stainless Steel Sink
Sink Insert 1/2 Solid Surface, 1/2 Stainless Steel Grate
Brushed Nickel Faucet w/Pull-Out Sprayer
12V Refrigerator
Flush Mount LP Cooktop
Decorative Backsplash

Bathroom

Porcelain Toilet
1-Piece Fiberglass Shower w/Extend-A-Shower Curtain
Single Lever Shower Sprayer w/Shutoff
Residential Size Medicine Cabinet w/Mirror Doors
Stainless Steel Sink
Brushed Nickel Metal Faucet
Decorative Backsplash
Full Length Mirror on Door

Bedroom

60 x 80 Residential Queen Bed w/Storage (2513, 2816, 2917)
Decorative Reading Lamps (2513, 2816, 2917)

Packages

Above & Beyond

Full Perimeter Welded Aluminum Frame (6 Sides welded together, no mechanical fasteners)
Axles - Torsion, EZ Lube, w/Self-adjusting Brakes
1-Piece Aluminum Roof
4,000 lb Rated Ramp Door
Low Angle Ramp for Easier Loading
Extruded Aluminum Floor - Garage & Kitchen w/ Removable Woven Vinyl Fitted Floor Covering
Composite Flooring in Bed, Bath, Hall w/ Woven Vinyl Floor Covering (No wood)
Dimmable Ceiling Lights Throughout
Composite Wall Panels (No wood)
Residential Solid Surface Countertops
50 Amp Distribution Panel - 120v Output w/12v Converter
50 Amp Shore Cord & Motorbase Plug

500 Series

Aluminum Exterior - Silver
Scissor Stabilizer Jacks - 5,000 lb Each - Total of Four
12v Roof Vents w/ Remote
Mill Finish Exterior Trim
Large Tinted Windows
(1) Scene Light (By entry door)
Linen Décor Package – Beige Walls, White Countertops, Pewter Cabinets OR Cashmere Décor Package – Gray Walls, Black Countertops, Silver Cabinets
Insulated Walls
5,000 lb Capacity Tie-down Rings in Floor
Happijac Bed- Residential Queen Mattress w/ Ladder
Tires on Aluminum Wheels w/ Stainless Steel Lug Nuts

700 Series

Aluminum Exterior - Choice of: Silver, White, Charcoal, Pewter, or Black
Electric Stabilizer Jacks
12v Roof Vents w/ Remote & Built-in Low Profile Rain Guard
Black Exterior Trim
Frameless Dual Pane Tinted Windows
(2) Scene Lights (Curb side)
Interior Wall Color - Choice of: Beige or Gray
Cabinets - Choice of: Silver, White, Charcoal, Pewter, or Black
Countertops - Choice of: White or Black
Upgraded E.P.S. Wall Insulation (R-7)
Airline Track Tie Down System - Recessed in Floor
Configurable Furniture Track System for Dinettes, Sofas, Tables (Ability to change floorplan)
Adjustable Shelving in Cabinets (Where applicable)
Goodyear Tires on Premium Aluminum Wheels
Skirting (Ground effects)
Skid Plates

Add Ons

500 Series

Deck Package (Railing w/ steps, vinyl roll-up screen wall at rear)
Happijac Sofa Beds (Under queen bed)
5.5kw Generator
Winterization (Mandatory Oct. 1 – Apr. 1)

700 Series

Deck Package (Railing w/ steps, vinyl roll-up screen wall at rear) (N/A w/ 3-season room)
Enclosed 3-Season Patio Room w/ Steps (N/A w/deck pkg)
Vinyl Roll-Up w/ Windows & Screens at Rear
Roof Storage Platform w/ Ladder
Ladder (To roof)
Power Awning w/ Scene Lights Road Side
Exterior Shower
2” Expanded Foam Insulation Under Floor (R-13)
Happijac Bed - Residential Queen, w/ Ladder
Happijac Sofa Beds (Under queen bed) (Only w/Happijac bed option)
30”, 45” or 72” Fold Down Table (Fits in furniture track system)
Additional 6’ Sleeper Sofa(s)
Pedestal Chair(s)
Overhead Cabinet(s) in Garage
Single or Triple Stud Tie Downs for Airline Track
TV in Bedroom
5.5kw Generator
Battery(s) - Lithium 100 Amp Hour
Back-Up Camera
Cell Signal Booster
Ramp - Drive Over Wheel Well
Winterization (Mandatory Oct. 1 – Apr. 1)

Upgrades

700 Series

Dinette w/ 4 Folding Chairs (IPO sleeper benches)
King Bed (2513, 2816 – IPO queen)
Tankless Water Heater - LP (IPO 6 gal. gas/electric)
Energy Package 2000 (400 Watts solar, 2000 watt inverter, 30 amp mppt charge controller – IPO 1000)
Energy Package 3000 (800 Watts solar, 3000 watt inverter, 60 amp charge controller, 400 amp hours lithium battery – IPO 1000)

---------------------------------------------------------

FIFTH WHEELS

Exterior Features

Hydraulic Leveling System
RotoFlex Pin Box
Power Awning w/ Light Strip
Entry Door w/ Tinted Window & Friction Hinge
Large Stainless Steel Fold-Out Grab Handle
Fold-Out Adjustable Step
Cableless Rear Ramp Door w/ Non-Slip Tread
Large Exterior Pass-Through Storage
Fuel Filling Station
Loading Lights at Ramp Door
RVIA Seal
Spare Tire on Gray Steel Wheel
Hide-A-Spare - EZ Access

Interior Features

8' Minimum Interior Height (Garage Area)
Fiberglass Batten Insulation in Attic (R-11)
Blackout Roller Shades
(1) Dinette w/ Benches (Sleeper)
(1) Sofa (Sleeper)
All Aluminum Cabinets & Drawers Throughout (No Wood)

Electrical

Energy Package 1000 (200 Watt Solar Panel, 1000 Watt Inverter, 30 Amp MPPT Charge Controller)
Generator Prep
(2) Battery Prep
High Definition 120v Smart TV
TV Prep in Bedroom
TV Prep Exterior
HD Digital TV Antenna w/ WiFi Prep
Stereo AM/FM Bluetooth w/ Interior & Exterior Speakers
Touchscreen User Control Panel
Backup Camera Prep
120v USB Power Outlets Throughout

Plumbing

DSI LP Gas/Electric Water Heater
Ducted LP Furnace
12v Water Pump w/ Winterizing Tap
City Water Hook Up w/ Fill
20' Sewer Hose w/ Storage Tube
Waste (Black) Tank Flush
3-Season Package
Exterior Water Spigot

Kitchen

Convection Microwave
Farmhouse Single Bowl Stainless Steel Sink
Sink Insert, 1/2 Solid Surface, 1/2 Stainless Steel Grate
Brushed Nickel Faucet w/ Pull-Out Sprayer
12v Refrigerator
3-Burner Cooktop w/ Oven
Decorative Backsplash

Bathroom

Porcelain Toilet
1 Piece Fiberglass Shower w/ Extend-A-Shower & Curtain
Single Lever Shower Sprayer w/ Shutoff
Residential Size Medicine Cabinet w/ Mirror Doors
Stainless Steel Sink
Brushed Nickel Metal Faucet
Decorative Backsplash

Bedroom

60 x 80 Residential Queen Bed w/ Storage
Decorative Reading Lamps
Full Length Mirror on Door
Washing Machine Prep

Packages

Above & Beyond

Full Perimeter Welded Aluminum Frame (All 6 Sides Welded Together - No Mechanical Fasteners)
Torsion Axles, EZ Lube, Self-Adjusting Brakes
1-Piece Aluminum Roof
4,000 lb Rated Ramp Door
Low Angle Ramp for Easy Loading
Extruded Aluminum Floor - Garage & Kitchen w/ Removable Woven Vinyl Floor Covering (No Wood)
Composite Flooring in Bed, Bath & Hall w/ Woven Vinyl Floor Covering (No Wood)
Dimmable Ceiling Lights Throughout
Composite Wall Panels (No Wood)
Residential Solid Surface Countertops
50 Amp Distribution Panel - 120v Output w. 12v Converter
50 Amp Shore Cord & Motorbase Plug

500 Series

Aluminum Exterior - Silver
12v Roof Vents w/ Remote
Mill Finish Exterior Trim
Large Tinted Windows
(1) Scene Light (By entry door)
Linen Décor Package - Beige Walls, White Countertops, Pewter Cabinets OR Cashmere Décor Package - Gray Walls, Black Countertops, Silver Cabinets
Insulated Walls
5,000 lb Capacity Tie Down Rings in Floor
Happijac Bed - Residential Queen Mattress w/ Ladder
Tires on Aluminum Wheels w/ Stainless Steel Lug Nuts

700 Series

Aluminum Exterior - Choice of: Silver, White, Charcoal, Pewter, or Black
12v Roof Vents w/ Remote and Built-in Low Profile Rain Guard
Black Exterior Trim
Frameless Dual Pane Tinted Windows
(2) Scene Lights (Curb side)
Interior Wall Color - Choice of Beige or Gray
Cabinets - Choice of: Silver, White, Charcoal, Pewter, or Black
Countertops - Choice of White or Black
Upgraded E.P.S. Wall Insulation (R-7)
Airline Track Tie Down System - Recessed in Floor
Configurable Furniture Track System for Dinettes, Sofas, Tables (Ability to Change Floorplan)
Adjustable Shelving in Cabinets (Where Applicable)
Goodyear Tires on Premium Aluminum Wheels
Skirting (Ground Effects)
Skid Plates
Second Fuel Tank, Isolated (4023, 4528)

Add Ons

500 Series

Deck Package (Railing w/ steps, vinyl roll-up screen wall at rear)
Happijac Sofa Beds (Under queen bed)
7.0kw Generator
Winterization (Mandatory Oct. 1 – Apr. 1)

700 Series

Deck Package (Railing w/ steps, vinyl roll-up screen wall at rear) (N/A w/ 3-season room)
Enclosed 3-Season Patio Room w/Steps (N/A w/ deck package)
Vinyl Roll-Up w/ Windows & Screens at Rear
Slider Tray in Pass-through Storage
Ladder (To roof)
Power Awning w/ Scene Lights Road Side
Exterior Shower
2” Expanded Foam Insulation Under Floor (R-13)
Happijac Bed- Residential Queen, w/ Ladder
Happijac Sofa Beds (Under queen bed) (Only w/ Happijac bed option)
30”, 45”, or 72” Fold Down Table (Fits in furniture track system)
Additional 6’ Sleeper Sofa(s)
Pedestal Chair(s)
Overhead Cabinet(s) in Garage
Single or Triple Stud Tie Downs for Airline Track
TV in Bedroom
7.0kw Generator
Battery(s) - Lithium 100 Amp Hour
Back-up Camera
Cell Signal Booster
Winterization (Mandatory Oct.1– Apr.1)

Upgrades

700 Series

Dinette w/ 4 Folding Chairs (IPO sleeper benches)
King Bed (IPO queen)
Tankless Water Heater - LP (IPO 10 gal gas/electric)
Energy Package 2000 (400 Watts solar, 2000 watt inverter, 30 amp mppt charge controller – IPO 1000)
Energy Package 3000 (800 Watts solar, 3000 watt inverter, 60 amp charge controller, 400 amp hours lithium battery – IPO 1000)
Slideout – Bedroom Window Seat

See us for a complete list of features and available options!

All standard features and specifications are subject to change.

All warranty info is typically reserved for new units and is subject to specific terms and conditions. See us for more details.

Due to the current environment, our features and options are subject to change due to material availability.

Favorite RVs

Save your favorite RVs as you browse. Begin with this one!

Great experience!
We spent several months looking for a new RV and were impressed with the selection at Cordelia RV. Our salesman JC listened to what we were looking for and was very patient while showing us many different options our first day there. Went back the next day with our interest narrowed to four RVs. Went

Jeff
Great experience!
I recently stopped by Cordelia RV Center with my wife to hopefully purchase a bumper pull RV trailer. J.C. ,our sales rep, was perfect. He answered all the questions I had without being a “salesman”. He didn’t have answers to all my questions so while we were chatting at his desk he called the Nash

Bryan
Highly recommended!
We recently purchased a 2018 Forest River Travel Trailer here at Cordelia RV. My husband and I are very happy with the trailer we’ve chosen and the service we’ve recieved. Tim Grogg helped us with the purchase which went very quickly and smoothly. Tim and everyone from the Service Office, Financing

Ofelia

We are here to help, call us at
707-864-8700 or Contact Us

We are here to help!

707-864-8700
Contact Us
Contact Sales

Cordelia RV is not responsible for any misprints, typos, or errors found in our website pages. Any price listed excludes sales tax, registration tags, and delivery fees. Manufacturer pictures, specifications, and features may be used in place of actual units on our lot. Please contact us @707-864-8700 for availability as our inventory changes rapidly. All calculated payments are an estimate only and do not constitute a commitment that financing or a specific interest rate or term is available.

Manufacturer and/or stock photographs may be used and may not be representative of the particular unit being viewed. Where an image has a stock image indicator, please confirm specific unit details with your dealer representative.

New 2023 ATC Trailers PLA 3619

3619 Floorplan

Specifications

Description

Features
